Wall Mounted Addressable Smoke Detector For Intelligent Fire Safety Smoke Alarm System
Introduction
CA9001 intelligent optical smoke detectors adopt the latest digital loop protocol.compatible with XHA intelligent fire alarm control panels. With digital communication.the detectors can raise fast alarm.It is designed based on light scattering technology with high performance chamber. suitable for detecting slow burning or smoldering fires.The detectors can be installed onto the common detector base DZ9000.
| Product name | Smoke Alarm Detector | Type | Addressable |
| Loop Bus wired | 2-wire Non-polarized | Monitor Current | ≤300uA |
| Alarm Currrent | ≤2mA | Dimension | Φ85*52 mm |
| Work voltage | DC17V～DC33V | Operating Environment | Temperature -10°C~+50°C Humidity ≤95%. |
| Weight | Weight:93g(with base) | Certification | CE |
Main Functions
•Electrically addressed, can be modified by programmer.
•Strong environmental adaptability due to drift compensation.
•Self-diagnostic.
•Communication:2 wires,Non-polarized.
Connection between Detector
Connection Diagram of Fire Alarm System
Product range
Conventional Fire Alarm System
Addressable fire alarm system
Gas Extinguishing control system
Beam Detector
4 wire smoke detectors with relay output.
2 wire Conventional smoke and heat detectors
Explosion-proof flame detector for fire alarm system
Standalone smoke detectors and combustable gas detector
Service
1. OEM &ODM service.
2. Provide technical support and after-sale service.
3. 1 year warranty.
4. Normally 15 working days lead time.
5. Welcome sample order.
|
|
