Explosion Proof Infrared Flame Detector For Fire Safety Alarm System
Introduction
The flame detector is a Infrared/ultraviolet flame detector
produced by our company. The equipment adopts high-performance
sensor (infrared wavelength 2.2μm/3.8μm/4.4μm/5.3μm, ultraviolet
wavelength 185 ~ 260nm), infrared wavelength 4.4μm sensor has high
sensitivity to carbon dioxide generated by hydrocarbon combustion.
The uv sensor is very sensitive to the ultraviolet radiation
emitted by the flame. Other sensors filter the ambient light and
ambient thermal radiation infection to better avoid the
interference of the ambient environment on the detection results.
Microcontroller technology, combined with sophisticated SMD process
manufacturing, has good repeatability and temperature and humidity
characteristics, long service life, easy to operate and other
advantages.
The flame detector can not only give early alarm to organic
compound combustion flame, but also has good alarm performance to
inorganic combustion flame.
It's suitable for the industries of petroleum, petrochemical
refineries, pipelines, chemical plant, coking plant, oil depot and
gas station, CNG, LNG, wine library, spray paint room, drilling
platform, city gas, boiler room, metallurgical industry, fire
engineering, ships, electric power industry and so on easy to
produce liquid or gas fire, smokeless fire and explosion.
Specifications
Product type:
XHA-IR1/IR2
KF715IR3
KF715UV
KF715UV/IR2
| Working voltage | 18V-32VDC |
| Interface | 1xNPT 3/4 |
| UV Flame Detector Detection Angle | 120 degree |
| Infrared Flame Detector Detection Angle | 90 degree |
| Level of protection | IP66 |
| Explosion Proof Level | Ex d lIC T6 Gb. Ex tD A21 IP66/IP67 T80℃ |
| Alarm Status | ≤50mA/24VDC |
| Fire response time | ≤10S |
| Detection range | Level I 25meters(33cm*33cm Ethanol fire) |
| Working environment | humidity ≤95%RH, no condensation |
Product range
Conventional Fire Alarm System
Addressable fire alarm system
Gas Extinguishing control system
Beam Detector
4 wire smoke detectors with relay output.
2 wire Conventional smoke and heat detectors
Explosion-proof flame detector for fire alarm system
Standalone smoke detectors and combustable gas detector
Service
1. OEM &ODM service.
2. Provide technical support and after-sale service.
3. 1 year warranty.
4. Normally 10 working days lead time.
5. Welcome sample order.
|
|
